Autel
Forty kW in a wall-mount box. Two outputs, a 21.5-inch screen, and a footprint that fits where a cabinet won't. The kind of DC unit a hotel or a dealership buys when it wants fast-ish charging without a new service.
Specifications
| Input | 480 V, 3-phase, no neutral, 60 Hz |
|---|---|
| Max output | 40 kW |
| Ports | 2 (CCS1 + CCS1, CCS1 + CHAdeMO, or single CCS1) |
| Output voltage | 150 to 950 V DC |
| Max output current | 133 A CCS1; 125 A CHAdeMO |
| Efficiency | 96% or better |
| Power factor | 0.99 or better |
| THD | under 5% |
| Dimensions (H x W x D) | 39.4 x 21.7 x 10.4 in (1000 x 550 x 265 mm) |
|---|---|
| Mounting | wall or floor pedestal |
| Protocol | OCPP 1.6J, upgradable to 2.0.1 |
| Connectivity | 4G, Wi-Fi, Ethernet |
| Vehicle protocols | ISO 15118 |
| Payment | app, RFID, credit card optional |
| Display | 21.5-inch touch screen |
| Cable length | 18 ft standard, 24.6 ft optional |
| Operating temp | -22 to 131 °F, derating above 113 °F |
| Enclosure | NEMA 3S |
| Warranty | 24 months, extensions available |
Certifications and standards
UL 2202, UL 2231-1, UL 2231-2, CSA No. 107.1-16, NEC Article 625, FCC Part 15 Class A.
Specs transcribed from the Autel MaxiCharger DC Compact datasheet. The Charge Sheet has no relationship with Autel. Specs come from the linked datasheet. The Charge Sheet takes no fee for this listing.
